ZC-638 phenol novolak type epoxy resin is a high viscosity liquid epoxy resin generated from the reaction of epichlorohydrin and linear phenol novolak type resin.
| Supplier | |
|---|---|
| Resin Type | Epoxy Resin |
| Pre-promotion Thixotropy | / |
| Molding Process | Filament Winding, Hand Lay-up, Pultrusion |
Epoxy resin products are mainly used in surface coatings, composites, for material bonding, and insulating materials; also widely used in the national defense, aerospace, road transport, automotive, aircraft, shipping, building construction, and electronics industries, and for electrical engineering, home appliances, telecommunications, energy, and food packaging.
| Property | Value | Unit | TM |
| Appearance | Clear liquid,no visible mechanical impurity | – | – |
| Epoxy equivalent | 170-210 | g/mol | GB/T 2895-2008 |
| Hydrolyzed chlorine | 0.5max | % | GB/T 7193-2008 |
| Inorganicchlorine | 4max | mg/kg | GB/T 7193-2008 |
| Volatile matter | 28-40 | mg/kg | GB/T 7193-2008 |
| Viscosity/25℃ | 8000-11000 | mPa•s | GB/T 7193-2008 |
True high-gloss paste wax.
Withstands high-temperature exothermic reactions of resins and does multiple releases easily.
Contains carnauba wax, synthetic waxes and high-temperature resistant resins for effective multiple releases of plastic parts through numerous cycles.
Brand:Polylite
Appearance:Light yellow transparent viscous liquid
Acid Value:19-25mgKOH/g
Viscosity，25℃:0.30-0.60Pa.s
Solid Content:59-66%
Thermal Stability,80℃:≥24h
Gel time:12-30min
Brand:Polylite
Physical State:liquid
Epoxy Equivalent (g/eq):184～190
Color (Gardner):1.0max
Flash Point (℃):150↑
Viscosity (cps, at 25℃)：12000～15000
Hydrolyzable Chlorine Content (ppm)：1000↓
Specific Gravity (g/cm³, 25℃)：1.16
Brand:Polylite
Appearance: Clear liquid,no visible mechanical impurity
Epoxy Equivalent (g/eq): 176–184
Color (Gardner): Max 1.0
Flash Point (℃): Above 150
Viscosity (cps, at 25℃): 8000–11000
Hydrolyzable Chlorine Content (ppm): Below 1000
Specific Gravity (g/cm³, 25℃): 1.16
Brand:Polylite
Appearance: Brown-yellow transparent liquid
Density: 1.05-1.07kg/L
Viscosity: 1 350±100cps
Solid content: 55±1%
Gelation time: 2 15±5min
Shelf life: 6 months (below 25℃)
Brand:Polylite
Appearance: light yellow transparent liquid
Density: 1.06±0.02kg/L
Viscosity: 430±150 cps (LVT#3-60rpm/25℃)
Solid content: 62±1.5%
Gelation time: 15-25 minutes
